Product Features
AnengJi LiFePO4 Home Battery Storage System provides portable wheeled and compact wall-mounted energy storage solutions, featuring advanced lithium iron phosphate (LiFePO4) battery cells and covering capacity options from 2.56kWh to 32kWh. Designed for home solar energy storage, backup power, off-grid energy systems, RVs, marine applications, and small commercial energy storage, AnengJI delivers flexible and reliable energy solutions for different scenarios.
Designed as a reliable home battery storage solution, AnengJI systems are suitable for residential solar energy storage, backup power supply, off-grid applications, RVs, marine energy systems, and small commercial energy storage projects.
Whether it is the flexible deployment models such as THS5 (2.56/5.12kWh), THS8 (8.03kWh), and THS15 (15.66/16.07kWh) portable battery systems, or space-saving wall-mounted models such as THS9.6 (10.24kWh), AnengJI provides suitable capacity options to meet various energy requirements.
Equipped with an intelligent Battery Management System (BMS) and automotive-grade LiFePO4 battery cells, AnengJI residential battery storage systems combine long service life, high safety performance, and smart energy management, making them an ideal home battery storage solution for global homeowners, installers, and energy partners.
Equipped with 360° universal wheels and an ergonomic handle, the portable battery storage system requires no fixed installation and can be easily moved between gardens, garages, RVs, and boats. It is suitable for emergency backup power, outdoor activities, and mobile energy applications.
All AnengJI LiFePO4 home battery storage systems use advanced battery cells, supporting ≥8,000 cycles at 80% Depth of Discharge (DOD) with a design lifespan of more than 10 years. This significantly reduces the Total Cost of Ownership (TCO) while ensuring stable long-term operation.
High-capacity models such as THS15 (15.66kWh) and THS32 (32kWh) are designed to provide continuous and reliable energy support for residential and small commercial loads.
Covering capacity ranges from 2.56kWh to 32kWh, with a maximum charge and discharge current of 200A, AnengJI battery storage systems can support various high-power devices including air conditioners, ovens, and electric tools.
For example, the THS20 (20kWh) model is suitable for multi-story villas and small commercial stores with higher peak electricity demand.
AnengJI residential energy storage systems have passed international certifications including CE, UN38.3, MSDS, UL1973, and IEC62619, meeting global transportation and import requirements for worldwide deployment.
AnengJI supports parallel connection for capacity expansion. For example, two THS16 (16kWh) battery units can be connected in parallel to create a 32kWh energy storage system.
Professional OEM/ODM services are available, including logo customization, parameter adjustment (such as THS5 series 25.6V 100/200Ah configurations), enclosure design, sample testing, and bulk production support.
| Application Scenario | Recommended Capacity (AnengJI Model) | Key Benefits |
|---|---|---|
| Home Backup Power | 5.12kWh (THS5), 8.03kWh (THS8) | Keeps refrigerators, routers, and other essential devices running during power outages |
| Home Solar Energy Storage | 10.24kWh (THS9.6), 15.66kWh (THS15) | Stores excess solar energy, reduces electricity costs, and improves energy independence |
| Off-Grid Living / Camping | 15.66kWh (THS15), 20kWh (THS20) | Provides independent power for air conditioners, induction cookers, and other high-power appliances |
| Small Business Backup Power | 16kWh (THS16), 32kWh (THS32) | Keeps POS systems, refrigeration equipment, and commercial loads operating during outages |
| RV / Marine Energy Storage | 8.03kWh (THS8), 16kWh (THS16) | Flexible mobile deployment for long-distance travel and outdoor power needs |
Residential Applications
Small and medium capacity models such as THS5 and THS8 are suitable for basic backup power needs, while larger models such as THS15 can be integrated with solar systems to maximize self-consumption and reduce electricity costs.
Commercial Applications
High-capacity models such as THS16 and THS32 provide reliable backup power for critical equipment and help reduce business interruption risks.
Mobile Applications
Portable wheeled models such as THS8 and THS15 are ideal for RVs, boats, and outdoor applications, providing flexible and convenient energy solutions.
✅ Flexible Design: Portable wheeled and wall-mounted configurations cover various residential and commercial applications.
✅ Advanced Technology: 8,000+ cycle life LiFePO4 battery technology ensures long-term reliability.
✅ Global Certifications: Certified for international markets with reliable quality assurance.
✅ OEM/ODM Capability: Customized solutions meet different branding and product requirements.
| Model | THS2.5 | THS5 | THS8 | THS5 | THS10 | THS16 | THS32 |
|---|---|---|---|---|---|---|---|
| Nominal Voltage | 25.6V | 25.6V | 25.6V | 51.2V | 51.2V | 51.2V | 51.2V |
| Nominal Capacity | 100Ah | 200Ah | 314Ah | 100Ah | 200Ah | 314Ah | 628Ah |
| Energy | 2560Wh | 5120Wh | 8038Wh | 5120Wh | 10240Wh | 16076Wh | 32153Wh |
| Product Dimensions (mm) | 425*330*150 | 560*440*150 | 520*430*250 | 560*440*150 | 665*565*150 | 717*500*240 | 902*850*250 |
| Maximum Operating Current | 100A | 150A | 200A | 100A | 200A | 200A | 300A |
| Cycle Life | 3000/6000 | 8000 | 3000/6000 | 8000 | 8000 | 8000 | 8000 |
| Charging Voltage | 28.8V (8S1P) | 57.6V (16S1P) | |||||
| Discharge Cut-off Voltage | 21.6V (8S1P) | 43.2V (16S1P) | |||||
| Design Life | ≥10 Years | ||||||
| Charging Temperature Range | 0℃~60℃ (Operation below 0℃ may affect available battery capacity) | ||||||
| Discharging Temperature Range | -20℃~60℃ (Operation below 0℃ may affect available battery capacity) | ||||||
| Storage Environment | 0℃~45℃ @ 60%±25% RH | ||||||
| IP Protection Rating | IP20 | ||||||
| Communication Protocol | RS485/CAN | ||||||
| Certifications | CB, CE, UN38.3, MSDS, UL1973 (Cell) | ||||||
What is a residential energy storage system?
A residential energy storage system stores electricity generated from solar panels or the grid and provides backup power for homes during outages or peak electricity periods.
What capacity options are available for AnengJi home battery storage systems?
AnengJi residential battery storage systems are available from 2.56kWh to 32kWh, including THS5, THS8, THS15, THS16, THS20, and THS32 models.
How long does a LiFePO4 home battery last?
LiFePO4 battery storage systems support more than 8,000 cycles at 80% DOD, with a design lifespan of over 10 years.
Can the battery storage system work with solar panels?
Yes. AnengJi home battery storage systems are compatible with mainstream solar inverters through CAN, RS485, and RS232 communication protocols for solar energy storage applications.
