Fast, Efficient DC Charging
Delivering 30kW or 40kW DC output, this Level 3 charger powers vehicles quickly and keeps operations running smoothly. It can add around 150–250 km (90–155 miles) of driving range in just 30 minutes, making it ideal for busy commercial sites and fleet applications.
Universal Compatibility
Choose from CCS1, CCS2, CHAdeMO, J1772, or GB/T connectors to fit different EVs across North America, Europe, and Asia. One unit supports multiple charging standards, making it perfect for international deployments and multi-brand charging networks.
Smart Connected Control
Built with OCPP 1.6J protocol and dual Ethernet + Wi-Fi connectivity, this DC fast charger supports cloud monitoring, remote updates, dynamic pricing, and live usage data tracking. It can be seamlessly integrated with your existing EV charging management platform for smarter operation.
Durable and Safe for Heavy Use
Each charger is tested under tough environmental and electrical conditions to ensure reliability. With high protection ratings, overload safeguards, and long-term stability, it’s made for continuous operation in high-traffic areas.
User-Friendly Touchscreen
The 4-inch color display gives real-time feedback on charging status, power level, cost, and alerts. Simple, clear, and easy to use — it improves the overall user experience and reduces support needs.
Certified Safety and Performance
Compliant with IEC 61851-1:2017 and IEC 62196-2:2016, this Level 3 EV charger offers full protection against overvoltage, overcurrent, leakage, and overheating. With IP54 dust and water resistance, it’s built to handle both indoor and outdoor environments.
Flexible Installation Options
Available in wall-mounted and pedestal-mounted configurations. Compact and easy to deploy, it adapts to various site layouts — from commercial parking lots to workplace charging zones.
Global Safety Certifications
Certified by CE, UL, CB, and TUV, ensuring consistent performance, reliability, and safety worldwide.
Rugged Metal Enclosure
Constructed with premium stainless steel, cold-rolled steel, and galvanized panels for superior corrosion resistance and long service life.
Warranty Options
Comes with a 2-year parts warranty, with optional 5-year extended coverage including labor for extra peace of mind.
Wide Application Range
Perfect for:
Commercial parking lots and public charging stations
Workplaces and fleet depots
Residential communities and multi-unit dwellings
Retail centers and shopping malls
| Product Name | Rated Power | |||
|---|---|---|---|---|
| Rated power | 30kW | 40kW | ||
| Installation method | vertical | |||
| Feeding method | Bottom in and out | |||
| Equipment size | 1610(including base)*550*200mm | |||
| Input voltage | AC380V±15% | |||
| Input frequency | 50±10Hz | |||
| Output voltage | 200-(750)1000VDC | |||
| Output current | 0-100A | 0-133A | ||
| Charging cable length | 5m | |||
| Accuracy | Level 1.0 | |||
| Efficiency | ≥95% | |||
| Human-computerinteraction | 4.3 inch bright color touch screen | |||
| Charge mode | Automatic charging/fixed power/fixed amount/fixed time | |||
| Charging method | Swipe card /Scan code /Password | |||
| Networking methods | Ethernet/4G | |||
| Executive standards | EC61851-1:2017;IEC62196-2:2016 | |||
| Working environment | Altitude:≤2000m;Temperature:-20°C~+50°C | |||
| Protection level | IP54 | |||
| Noise | Forced air cooling | |||
| MTBF | 17520h | |||
| Communication protocol | OCPP 1.6J | |||
How fast can a 30kW or 40kW DC fast charger charge an electric vehicle?
A 30kW / 40kW DC fast charger can typically add 90–155 miles (150–250 km) of driving range in about 30 minutes, depending on the vehicle’s battery size and state of charge. That’s 4–6 times faster than a standard Level 2 AC charger. It’s an excellent choice for commercial parking lots, fleet charging depots, and public charging stations.
What types of EVs are compatible with this charger?
This Level 3 DC fast charger supports multiple international charging standards, including CCS1, CCS2, CHAdeMO, GB/T, and optional J1772 connectors. It works with most major EV brands such as Tesla (with adapter), Volkswagen, Hyundai, BYD, Ford, Nissan, and BMW — making it ideal for multi-brand charging networks.
Can this DC fast charger be integrated with charging management platforms?
Yes. The charger supports OCPP 1.6J protocol, allowing it to connect with most EV charging management systems. Through OCPP, operators can monitor charging sessions in real time, manage users, set pricing rules, perform remote diagnostics, and push firmware updates — all from a single dashboard.
Is the charger suitable for outdoor installation?
Absolutely. The IP54-rated metal enclosure protects the unit against dust and water, making it perfect for outdoor environments such as public parking lots, highway rest stops, workplaces, and residential communities. It’s designed to withstand harsh weather conditions and continuous high-traffic use.
What installation options are available?
The 30kW / 40kW DC fast charger supports floor-standing installation. Its compact vertical design makes it easy to integrate into existing infrastructure with minimal site modification. Power is supplied from the bottom, ensuring clean and secure cable management.
What safety features does this EV charger have?
The charger is equipped with multiple protection systems, including overvoltage, undervoltage, short circuit, overload, ground fault, overtemperature, emergency stop, and leakage protection. It meets IEC 61851-1:2017 and IEC 62196-2:2016 standards to ensure safe, stable operation 24/7.
Can I monitor and control the charger remotely?
Yes. The unit offers Ethernet, 4G, and Wi-Fi connectivity, allowing operators to monitor usage data, energy consumption, and device status from anywhere. Remote access also enables load balancing, dynamic pricing, and troubleshooting without on-site visits — saving both time and costs.
What kind of maintenance does it require?
The 30kW / 40kW DC charger is designed for low-maintenance operation. Routine visual inspections, connector cleaning, and software updates through OCPP are typically all that’s needed. Its robust metal housing and forced-air cooling system are built for long-term reliability in commercial settings.
Does the charger come with a warranty?
Yes. Every unit comes with a 2-year parts warranty, with optional 5-year extended coverage available. This includes both hardware and technical support, ensuring long-term peace of mind for commercial operators.
What are common applications for this DC fast charger?
This model is ideal for:
Commercial parking lots and public charging stations
Fleet depots and logistics hubs
Residential communities and multi-unit dwellings
Office buildings and retail centers
Highway service areas
Its high charging speed, universal compatibility, and smart management features make it a top choice for scalable EV infrastructure.
Level 3 DC fast charging is the quickest way to power up an electric vehicle today. Unlike Level 2 AC chargers, which can take hours, a DC fast charger can bring most EVs from 10% to 80% in just 15 to 40 minutes under ideal conditions. It’s the go-to choice for locations where time matters — highways, gas stations, logistics hubs, and other busy commercial sites.
Lightning-fast charging:
With output power ranging from 30kW to 480kW (most common models are 30–360kW), these chargers drastically reduce downtime and get vehicles back on the road quickly.
High efficiency for commercial use:
In about 30 minutes, most vehicles can gain 125–300 miles (200–480 km) of driving range — perfect for long-distance routes or fleet operations where every minute counts.
A business advantage:
Adding DC fast chargers can turn your gas station, shopping center, or hotel into a destination. Drivers stay longer, spend more, and associate your brand with innovation and sustainability.
Because of their high power draw and the need for specialized installation, DC fast chargers are typically installed at commercial sites with strong grid capacity — not at private homes or standard office buildings. They’re built for places that serve many vehicles daily and require dependable uptime.
AnengJi offers a complete range of commercial DC fast charging solutions, supporting CCS, CHAdeMO, and GB/T standards to serve all major EV models worldwide.
Power options span from 30kW up to 480kW, allowing businesses and operators to scale according to site demand.
Our chargers are engineered for long-term reliability, network compatibility, and easy integration — helping global partners build high-performance, high-utilization EV charging stations that keep drivers moving and businesses growing.
